Application
Static applications for flange and fume ducts, concrete lids and glass
joints, heat exchanger, chemical reactors, hand and manholes, glass line
flanges, hydraulic, pneumatic and water systems, pharma and food
processing equipments.
Technical Data
- 100% pure PTFE without any fillers and pigments.
- pH 0-14 (except molten alkali and elemental fluorine)
- Temperature ranges -60 °C to +260°C
- Pressure ranges from Vacuum to 20bar
- Density 0.8 gm/cc (+ 0.1)
Spool Ordering Information
| Size | mm | 3 | 5 | 6 | 8 | 10 | 12.5 | 14 | 16 | 19 | 20 | 22 | 25 |
| inch | 1/8 | 3/16 | – | 5/16 | – | 1/2 | 9/16 | 5/8 | 3/4 | – | – | 1 | |
| Packaged(±5%) | mtr | 50 | 20 | 20 | 20 | – | – | – | – | – | – | – | – |
| – | – | 10 | 10 | 10 | 10 | 10 | 10 | – | – | – | – | ||
| – | – | – | – | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
*customized size and length available on request.
